SUL-DLN0530E/Fashion Retail

30W Rich Colors

xianbideng2
xianbideng
30W Rich Colors & Increased Contrast
High Color Rendering
Showcases Merchandise and makes an impact
Description Dimension(mm)
APPLICATION:
xianbideng20W-l
Supermarket, retail, mall, hotel.
CONSTRUCTION:
Die-cast aluminium main body and frame; stainless steel rotation hinge. Rotation ring with safety cover in a high resistance thermoplastic material.
MOUNTING:
Screw-fastening in ceilings of thickness 1–25mm; preparation hole Φ155mm.
Performance Summary Application
Luminous flux: 2200lm
SUL-DLN0530E-Crispcolor01
SUL-DLN0530E-Crispcolor02
Luminous flux efficacy: 75lm/W
CCT: 3000k
Colour rendering index: 90
Beam angle: 15°/24°/38°/60°
LED type: COB
LED amount: 1pcs
Lumen maintenance: 3,000 hrs
System wattage: 30Watt Color Bin Definitions
Input voltage: 220-240VAC 50-60Hz color-bin-color
Power factor: >0.9
Dimming range: non-dimmable
Electrical safety: class I
IP rating: IP20
Operation temp.: -20℃ ~ +45℃
Dimensions: Φ165mm x 145mm Installation
Cutout: Φ155 xianbideng-az
Rotation: 355°
Swivels: 65°
Luminaire material: die-cast aluminum
Finish: white/black
Packing size: 550mm x 370mm x 315mm
Net weight: 1.3Kg
Gross weight: 17Kg
Pieces/carton: 12pcs
30W Rich Colors
